VFH Electric Chain Hoist
VFH Electric Chain Hoist is an electric chain lifting equipment. It is mainly used for lifting, lowering and short-distance horizontal transportation of heavy objects, and is suitable for small processing workshops, mold maintenance, storage warehouses, equipment assembly, vehicle repair and maintenance, construction site fixed-point lifting and other industries/scenarios. This product features simple installation, compact body, dust-proof chain storage bag, emergency stop button, overload protection, and convenient operation. It can help customers solve problems such as lifting heavy objects at workstations, the difficulty of manual lifting of heavy objects, poor protection during fixed-point lifting, and the difficulty of installing lifting equipment in narrow spaces.
Share to
Features
- Permanent magnet frequency conversion technology, stable lifting and falling without shaking. Intelligent integrated control appliances can save energy by more than 45%. Electrical control 4v low voltage is safe and reliable, no worry about electric shock
- Overload and overheat protection can ensure safe and durable, and high and low speed can be switched at will, which make the machine suitable for different scenarios
- Optional-accurate weight display and real-time monitoring, record keeping for query, wireless control + wireless communication
- Double safety brake device: When the power is off, the motor decelerates instantly and the mechanical ratchet brake take action at the same time.
- The switch line and power line are designed separately, which is easy to install.
- Small button switch, easy operation
- The main unit is small in size and light in weight and can be moved quickly.
- Single 100V-240V power supply can be customized for DC12V, 18V, 24V, 36V, 48V
- When the chain reaches the upper or lower limit, the micro switch will be triggered, and the circuit is automatically cut off to prevent machine collision.
Specification
| Specification Model | Lifting capacity (kg) | Variable frequency motor power(KW) | Lifting Speed（m/min） | Brake | Lifting height（m） | chain (mm) | Power cable length(m) | Control handle cable length (m) | Hook type | N.W(kg) | G.W(kg) | Package size(cm) | |
| Low | Hight | ||||||||||||
| NH-300DS | 300 | 1.5 | 5 | 9 | electric +machanic | 3 | 5×15 | 4.5 | 2.5 | H105 | 17 | 19 | 50×30×35 |
| NH-500DS | 500 | 1.5 | 4 | 6.8 | 17 | 19 | |||||||
| NH-500DSK | 600 | 2.5 | 6 | 10 | 17 | 19 | |||||||
| NH-1000DS | 1000 | 2.5 | 4 | 6.8 | 7×21 | H10 | 20 | 23 | |||||
| NH-1000DS/2 | 1000 | 1.5 | 2 | 3.4 | 5*15×2 | H102 | 21 | 24 | |||||
| NH-2000DS | 2000 | 2.5 | 2 | 3.4 | 7*21×2 | H202 | 29 | 32 | 50×40×35 | ||||
