Project Introduction
This is a public international tender for water intake renovation in Pakistan. A total of 8 sets 10 ton European style low headroom double girder wire rope trolley hoists were supplied, including full sets of matched rail tracks and fasteners. The hoists are installed outdoor on top of reinforced concrete dividing walls, for lifting & cleaning trash racks and gates at the bottom of 10 meter deep intake channels.
Main Technical Specification
- Rated capacity:10t SWL, Duty group FEM 2M for heavy duty frequent operation
- Lifting height:10 m, rail gauge 3890 mm c c, VFD control for hoisting & cross travel
- Ambient: outdoor installation, max ambient temperature +50℃, C3/C4 heavy duty corrosion protection; weather proof canopy for motors, brakes and gear boxes
- Key components: SEW hoist & travel motor with fail safe brake; VFD from Schneider/Siemens/ABB; galvanized outdoor steel wire rope; forged swivel hook with safety latch; IP55 control cabinet, 24 48V low voltage control circuit
- Safety devices: overload limiter, upper/lower limit switch, rope break anti drop protection, end stops & buffer, emergency stop, anti collision unit for adjacent trolleys
- Deliverables: trolley hoist + complete rail system; static & dynamic wheel load calculation report for civil structure verification.
- Factory acceptance: witness test required (125% static load test, 110% dynamic load test) before shipment; full set of English documentation, warranty ≥12 months.
Highlights
Strict international bidding project, all design calculation, material certification, and witness inspection and anti corrosion measures must comply with European FEM standards. Demonstrates our capability for complete overseas heavy duty water conservancy projects.
